Exploring the new DevExpress Universal 2013 v13.2 release

December 4, 2013

Introduction

DevExpress is one of the leading providers of developer components for Microsoft Windows based solutions. In fact, this year they are celebrating their 15 year anniversary as a company. In their latest suite of controls, they have a very large assortment of different controls for a variety of technology platforms, such as:

  • WinForms (120+ Controls)
  • ASP.NET (90+ Controls)
  • ASP.NET MVC (50+ Controls)
  • WPF (80+ Controls)
  • Silverlight (75+ Controls)
  • Windows 8 XAML
  • Reporting
  • Dashboard
  • Document Server
  • XAF Application Framework
  • DevExtreme Mobile

In this review of the 2013 v13.2 release, I will highlight what is new in the respective areas. But first, let’s install the suite.

Installation of the DevExpress Universal 2013 v13.2 suite

DevExpress distribute their components in an installer that provides a very user friendly and streamlined way of setting up your environment. If you simply wants to download a 30 day evolution, just head over to the Free Universal Trial page. That downloads a small web installer, which is a very clean simple a nice looking installer that makes installation a breeze:

DevExpressInstall1DevExpressInstall2DevExpressInstall3DevExpressInstall4    DevExpressInstall5

By the way, that’s a really nice looking installation wizard. If you want to do something similar for Windows Desktop, DevExpress provides that kind of look and feel in their WinForms components.

Windows Forms


Windows Forms still lives on and DevExpress keeps on adding new exciting controls and features to their existing line up. In the 13.2 release these are the new features:

Grid Enhancements

The Grid View is a very competent data grid component that is now getting these exiting additions:

Windows Explorer View

This view will mimic the standard Windows Explore way of displaying items.

WinForms1

Inline Data Editing

By double clicking a row, the inline editing capabilities are enabled:

WinForms2

Web Style Row Editing

This editing style can be used with check boxes, both on line level and column header level in order to easily select single, all or multiple items. WinForms3

ASP.NET


Ribbon Control (Web Forms and MVC)

The ribbon control was introduced in Microsoft Office 2007 and has been a great productivity improvement. Its way of categorizing command is now finally possible in your web page.

ASPNETRibbon1

Spreadsheet Control (Web Forms)

Excel in a web page? Well, this would have been something crazy a coupe of years ago, but now DevExpress has made it possible. Just look at the different formulas you can let the mathematical inclined user select from:

ASPNETSpread1

Spreadsheet Control Overview

ASPNETSpread3

Autosum functions

ASPNETSpread4

Financial functions

ASPNETSpread6

Text functions

ASPNETSpread5

Logical functions

ASPNETSpread7

Date & Time functions

ASPNETSpread8

Lookup and Reference functions

ASPNETSpread9

Math & Trig functions

ASPNETSpread10

More functions

If that isn’t enough, let your users knock themselves out by adding charts to their spreadsheet. Just look at all of these charts they can add:



ASPNETSpreadCharts1

Charts overview

ASPNETSpreadCharts2

Column chart types

ASPNETSpreadCharts3

Line chart types

ASPNETSpreadCharts4

Pie chart types

ASPNETSpreadCharts5

Bar chart types

ASPNETSpreadCharts6

Area chart types

ASPNETSpreadCharts7

Scatter chart types

ASPNETSpreadCharts8

Other chart types

This is almost too crazy, your users will love you for this.

Grid Batch Editing (Web Forms and MVC)

With this new addition to the Grid control, multiple changes can be edited client side, and when the user clicks Save Changes, all of the changes will be pushed back to the server in one request. Very handy to minimize the chattiness of your web page.

ASPNETGridBatch1

Grid batch editing

Application Themes (Web Forms and MVC)

Users really likes to personalize the look and feel of their workplace, and with the Application Themes you can let them change the web page, or even the web application to something that’s more of their liking.

ASPNETThemes1

Application themes

Token Box Control (Web Forms and MVC)

This is a very popular control for letting the user select multiple items from a list. It makes it very easy to search for items, as well as remove selected items.

ASPNETTokenBox1

ASPNETTokenBox2

When the user types in the input box, it will do an automatic search and highlight found items.

Custom Color Picker (Web Forms and MVC)

Ever wanted to able to select colors from a color palette? It couldn’t be easier than with this control. It supports custom number of columns, custom palettes and even select a complete custom color from a color picker.

ASPNETColor1

Color picker

ASPNETColor2

Color picker with custom palette

ASPNETColor3

Custom color



Form Layout Extension (MVC)

If you ever have been struggling with getting the layout of your controls looking nice, this MVC control will makes it very easy to make a well-designed layout:

ASPNETLayout

Grid Lookup Extension (MVC)

This is a very powerful extension to a drop down control. It essentially lets you display a grid in the drop down, complete with check-boxes for multiple selections and additional data for each item in the data list.

ASPNETGridLookup1

Rating Extension (MVC)

This is a standard rating control that enables you to let the user enter their rating for a particular item based on the familiar 5-start principle.

ASPNETRating1

WPF


Spreadsheet Control

Much like the ASP.NET WebForms version discussed above, this is also a very comprehensive and complete spread sheet control. It has all of the charts and formulas from its ASP.NET sibling, but it also adds some more nice touches.

WPFSpread1

WPF spreadsheet control

WPFSpread4

Formulas

WPFSpread2

Charts

WPFSpread3

Page layout

WPFSpread5

Data sorting

WPFSpread6

View



PDF Viewer

With the WPF PDF Viewer control, you can easily add PDF reading capabilities. Functions like Print, Find, Zoom in and out are available.

WPFPDFViewer1

Themes

As with the ASP.NET themes control, this WPF version also allows the user to select a them of their choice:

WPFThemes1

Sparkline Control

To present trending information in a data grid, DevExpress has added the possibility to add a Sparkline control.

WPFSparklines1

You can either add lines:

WPFSparklines2

or areas:

WPFSparklines3

Windows 8 Dialog and Message Box

One thing that Windows Store apps have is the new message box that covers the whole width of the screen. Now you can easily achieve this in your WPF application by using this control:

WPFWindows8MB1

Windows 8

Please see my separate post about the DevExpress Windows 8 XAML controls.

Conclusion

I have found that the DevExpress Universal suite of controls are very professional and slick looking. All of the controls seems to enable you as a developer creating good performing application, whether it’s an ASP.NET based application, a Windows 8 Store App, or a more traditional WinForms, WPF or Silverlight application. Please take the 30 day trial for a spin and see how easy it is to make your users having a great consistent Windows Store app experience.
Disclosure of Material Connection: I received one or more of the products or services
mentioned above for free in the hope that I would mention it on my blog. Regardless, I
only recommend products or services I use personally and believe my readers will enjoy.
I am disclosing this in accordance with the Federal Trade Commission’s 16 CFR, Part 255:
“Guides Concerning the Use of Endorsements and Testimonials in Advertising.”

Add Windows 8 Hub Tiles to your app using the DevExpress Windows 8 XAML Hub Tiles control

December 3, 2013

Introduction

This is an additional post to my DevExpress review posted here.  In this post I will focus on how you can add Windows 8 Hub Tiles to your app using DevExpress Windows 8 XAML components.

Windows 8 XAML components

Unless you have been living under a rock for the last 2 years, it will not as a surprise to you that the new uCheckser interface paradigm in the Windows Store Apps is drastically different than the way Windows Desktop application has been looking for the last 20 years or so. DevExpress is now offering a new set of Windows 8 XAML based controls that perfectly falls into the new design language. In this mini review, I will be looking at the Hub Tile Components.

The first thing you will notice when you start Windows 8 is a “sea” of tiles that let you quickly get an overview and status of your most common application and start any of them. DevExpress is offering a new exciting component that lets you very easily mimic the Windows Start Screen; it’s called the Hub Tiles control.

DevExpressHubTiles

Windows 8 Hub Tiles

In this demo I will be walk you through how to create a simple application that will benefit from the DevExpress Hub Tile component. It’s a simple recipe app with static data, but in a real world scenario it would either connect to a web service or at least a local database.

Creating a project

When creating a Windows Store app, DevExpress installs a handful of templates in the Template Gallery that makes the process even simpler.

DevExpressProjWiz1DevExpressProjWiz2 DevExpressProjWiz3

A nice touch is that the template automatically create a MVVM (Model View ViewModel) based project, a paradigm that is very common in XAML based development. DevExpress provides base classes that makes data binding and INotifactionPropertyChanged events easily consumed.

So let’s first create a data source for our Hub Tiles. This is very convenient to do, so you can data bind the visual elements in the tile to some data.



Let’s see how we easily can present this data in a Hub Tile.

First, let’s get an overview of the different type of tiles that are available:

  • Slide Hub Tile.
    This is a tile that has 2 sides (front and back). It will slide up the contents of the data that it’s bound to in sequence.
  • Swing Hub Tile.
    This tile also has 2 sides, but it “swings” the content back and forth.
  • Hub Tile.
    A tile that has 2 sides (front and back). It will switch between the 2 sides automatically in sequence.

So let’s pick the Slide Hub Tile and see how we easily can bind it to our data.



The result is a Hub Tile that will Slide the images of your recipe up within the tile:

DevExpressResult1 DevExpressResult2

Conclusion

I have found that the DevExpress Windows 8 XAML controls makes it very easy to implement the Windows Store user interface design language into your own application. It abstracts the tedious work of implementing Windows Store user controls functionality yourself.

Please take the 30 day trial a spin and see how easy it is to make your users having a great consistent Windows Store app experience.



Disclosure of Material Connection: I received one or more of the products or services
mentioned above for free in the hope that I would mention it on my blog. Regardless, I
only recommend products or services I use personally and believe my readers will enjoy.
I am disclosing this in accordance with the Federal Trade Commission’s 16 CFR, Part 255:
“Guides Concerning the Use of Endorsements and Testimonials in Advertising.”

Azure Role does not start, Could not load file or assembly ‘System.Web.Mvc, Version=4.0.0.0

October 26, 2013

The sub title of this post is also; how to do pre-web.config assembly binding for Windows Azure.

So I upgraded my ASP.NET MVC 4 Web Application to MVC 5 and published to my Windows Azure Web Role/Worker Role.

What might a little unusual is that I have my web application and the worker role in the same project/role, since the workload is currently very little. In fact, I have a Web Role that spawn background tasks using classes that inherits from RoleEntryPoint.

After upgrade and publish, my worker role did not start. And even though I had enabled all the logging I could think of, the only error I got was that WaIISHost.exe has crashed with an Exception. No stack trace. Bummer.



So I had to remote desktop into one of the roles, firing up DebugView.exe and I deployed. This is what I got:

[3464] Microsoft.WindowsAzure.ServiceRuntime Critical: 201 :
[3464] Role entrypoint could not be created:
[3464] System.TypeLoadException: Unable to load the role entry point due to the following exceptions:
[3464] — System.IO.FileLoadException: Could not load file or assembly ‘System.Web.Mvc, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35′ or one of its dependencies. The located assembly’s manifest definition does not match the assembly reference. (Exception from HRESULT: 0×80131040)
[3464] File name: ‘System.Web.Mvc, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35′
[3464]
[3464] WRN: Assembly binding logging is turned OFF.
[3464] To enable assembly bind failure logging, set the registry value [HKLM\Software\Microsoft\Fusion!EnableLog] (DWORD) to 1.
[3464] Note: There is some performance penalty associated with assembly bind failure logging.
[3464] To turn this feature off, remove the registry value [HKLM\Software\Microsoft\Fusion!EnableLog].
[3464]
[3464] —> System.Reflection.ReflectionTypeLoadException: Unable to load one or more of the requested types. Retrieve the LoaderExceptions property for more information.
[3464] at System.Reflection.RuntimeModule.GetTypes(RuntimeModule module)
[3464] at System.Reflection.RuntimeModule.GetTypes()
[3464] at System.Reflection.Assembly.GetTypes()
[3464] at Microsoft.WindowsAzure.ServiceRuntime.RoleEnvironment.GetRoleEntryPoint(Assembly entryPointAssembly)
[3464] — End of inner exception stack trace —
[3464] at Microsoft.WindowsAzure.ServiceRuntime.RoleEnvironment.GetRoleEntryPoint(Assembly entryPointAssembly)
[3464] at Microsoft.WindowsAzure.ServiceRuntime.RoleEnvironment.CreateRoleEntryPoint(RoleType roleTypeEnum)
[3464] at Microsoft.WindowsAzure.ServiceRuntime.RoleEnvironment.InitializeRoleInternal(RoleType roleTypeEnum)

Hmm.. thats odd, since when I upgraded to MVC 5, I also has these assembly bindings in my web.config:

<dependentAssembly>
<assemblyIdentity name=”System.Web.Mvc” publicKeyToken=”31BF3856AD364E35″ culture=”neutral”/>
<bindingRedirect oldVersion=”0.0.0.0-5.0.0.0″ newVersion=”5.0.0.0″/>
</dependentAssembly>

So let’s enable Fusion logging. It gave me a little bit more details:

[1988] Microsoft.WindowsAzure.ServiceRuntime Critical: 201 :
[1988] Role entrypoint could not be created:
[1988] System.TypeLoadException: Unable to load the role entry point due to the following exceptions:
[1988] — System.IO.FileLoadException: Could not load file or assembly ‘System.Web.Mvc, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35′ or one of its dependencies. The located assembly’s manifest definition does not match the assembly reference. (Exception from HRESULT: 0×80131040)
[1988] File name: ‘System.Web.Mvc, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35′
[1988]
[1988] Assembly manager loaded from: D:\Windows\Microsoft.NET\Framework64\v4.0.30319\clr.dll
[1988] Running under executable F:\base\x64\WaIISHost.exe
[1988] — A detailed error log follows.
[1988]
[1988] === Pre-bind state information ===
[1988] LOG: DisplayName = System.Web.Mvc, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35
[1988] (Fully-specified)
[1988] LOG: Appbase = file:///F:/approot/bin
[1988] LOG: Initial PrivatePath = F:\approot\bin
[1988] Calling assembly : Mvc.Mailer, Version=1.0.0.0, Culture=neutral, PublicKeyToken=null.
[1988] ===
[1988] LOG: This bind starts in default load context.
[1988] LOG: Using application configuration file: F:\base\x64\WaIISHost.exe.Config
[1988] LOG: Using host configuration file:
[1988] LOG: Using machine configuration file from D:\Windows\Microsoft.NET\Framework64\v4.0.30319\config\machine.config.
[1988] LOG: Post-policy reference: System.Web.Mvc, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35
[1988] LOG: Attempting download of new URL file:///F:/approot/bin/System.Web.Mvc.DLL.
[1988] WRN: Comparing the assembly name resulted in the mismatch: Major Version
[1988] ERR: Failed to complete setup of assembly (hr = 0×80131040). Probing terminated.
[1988]
[1988] —> System.Reflection.ReflectionTypeLoadException: Unable to load one or more of the requested types. Retrieve the LoaderExceptions property for more information.
[1988] at System.Reflection.RuntimeModule.GetTypes(RuntimeModule module)
[1988] at System.Reflection.RuntimeModule.GetTypes()
[1988] at System.Reflection.Assembly.GetTypes()
[1988] at Microsoft.WindowsAzure.ServiceRuntime.RoleEnvironment.GetRoleEntryPoint(Assembly entryPointAssembly)
[1988] — End of inner exception stack trace —
[1988] at Microsoft.WindowsAzure.ServiceRuntime.RoleEnvironment.GetRoleEntryPoint(Assembly entryPointAssembly)
[1988] at Microsoft.WindowsAzure.ServiceRuntime.RoleEnvironment.CreateRoleEntryPoint(RoleType roleTypeEnum)
[1988] at Microsoft.WindowsAzure.ServiceRuntime.RoleEnvironment.InitializeRoleInternal(RoleType roleTypeEnum)

Ok, so now I know which DLL tries to load the older MVC 4 assemblies, but why isn’t my binding taking care of that?

As it turns out, since I am using my combined codebase for the worker role, essentially my Application.Web.dll, the web.config is of course not used when the WaIISHost.exe is loading that assembly. So what I had to do is to create a Application.Web.dll.config in my project root, set it to Content and Copy Always(or Copy If Newer), and copy paste in all my Assemlby Binding elements.

Now, the AZure WAIIHost.exe picks it up correctly, and my role is started correctly.
